An arc flash study is more than a compliance task—it’s a critical safety analysis that protects your people, prevents catastrophic equipment failure, and keeps your facility running. But for many managers and engineers, navigating the requirements, costs, and technical details can feel overwhelming.
At ArcFlash Study Guru, one of the leading arc flash and electrical safety service providers in the USA, we specialize in helping companies conduct precise, reliable studies that keep workplaces safe and compliant.
This guide breaks down everything you need to know about arc flash studies. We will explain the process in plain English, clarify the standards from OSHA and NFPA, and provide actionable steps for everything from data collection to choosing the right engineering partner. You will learn what a study delivers, how much it should cost, and how to use the results to create a safer, more resilient electrical system.
Whether you’re a facility manager trying to budget, an EHS officer ensuring compliance, or an engineer tasked with execution, this article will provide the clarity you need to manage arc flash risk effectively.
What Is an Arc Flash Study? (Plain-English + Tech Basics)
An arc flash study, also known as an arc flash hazard analysis or assessment, is an engineering investigation into a facility’s electrical system. Its primary purpose is to calculate the potential severity of an arc flash at every point where an employee might work and to determine the appropriate safety measures.
At its core, an arc flash study determines the incident energy—the amount of thermal energy a worker would be exposed to during an arc flash event. This energy is measured in calories per square centimeter (cal/cm²). For perspective, a burn can occur at just 1.2 cal/cm². The study calculates this value at specific locations, typically at the front of electrical enclosures where someone might perform work.
A complete study delivers three key components:
These three studies are related but distinct. A short-circuit study and a coordination study are prerequisites for an accurate arc flash study.
Study Type | Purpose | Key Question Answered |
Short-Circuit Study | Calculates the maximum fault current available at each point in the system. | “How much energy will the system deliver during a fault?” |
Coordination Study | Ensures protective devices (breakers, fuses) operate in sequence to isolate a fault with minimal disruption. | “Will the correct breaker trip first to limit the outage?” |
Arc Flash Study | Uses data from the other two studies to calculate incident energy and define safety requirements. | “How dangerous is a fault, and what PPE is required to work safely?” |
Yes, regulatory bodies mandate that employers assess electrical hazards, and an arc flash study is the industry-accepted method to do so.
OSHA requires employers to make a “reasonable estimate” of the incident heat energy a worker could be exposed to. While OSHA doesn’t explicitly state “perform an arc flash study,” a formal study based on engineering calculations (like IEEE 1584) is the only defensible way to meet this requirement for complex systems. Relying on generic tables is often insufficient and may not hold up under scrutiny after an incident.
The NFPA 70E, Standard for Electrical Safety in the Workplace, is the “how-to” guide for implementing OSHA’s rules. Key requirements include:
In Canada, CSA Z462 mirrors NFPA 70E. The legal imperative is strengthened by Bill C-45, which holds organizations and their leaders criminally liable for failing to take reasonable steps to prevent bodily harm. Demonstrating due diligence requires a formal arc flash hazard analysis.
You need a new or updated arc flash study when:
Callout: Do You Need an Arc Flash Study?
Answer these two questions to find out:
A thorough arc flash study is more than just calculations; it’s a comprehensive process.
The accuracy of the study depends entirely on the quality of the input data. This involves a detailed on-site survey to gather information like transformer ratings, conductor lengths and sizes, and protective device settings.
(A downloadable PDF checklist would be linked here.)
The engineer must build a precise model of your system and document key assumptions based on IEEE 1584-2018 standards:
A comprehensive report should include:
Labels must be placed on equipment that is likely to be worked on while energized. Per NFPA 70E, the label must display at least one of the following:
Most labels also include the arc flash boundary and nominal system voltage for quick reference.
(A sample label image would be displayed here.)
Costs vary based on facility size, complexity, and data availability.
Facility Type | Typical Gear Count | On-Site Hours | Typical Cost Range | Duration |
Small Plant | < 75 buses | 16-24 hours | $8,000 – $15,000 | 2-4 weeks |
Mid-Size Facility | 75 – 250 buses | 30-50 hours | $15,000 – $35,000 | 4-8 weeks |
Campus/Multi-Building | 250+ buses | 60+ hours | $35,000+ | 8-16 weeks |
Note: These are industry estimates. Request a custom quote for an accurate price.
Engineers use specialized software and follow the IEEE 1584-2018 Guide for Performing Arc-Flash Hazard Calculations.
The 2018 update to the IEEE 1584 standard introduced more complex, but more accurate, calculation models. Key changes include:
The practical effect is that results can be significantly different—sometimes higher, sometimes lower—than those from older study methods.
NFPA 70E provides tables to determine a PPE Category without a full study. However, this method has strict limitations.
Comparison | Full Arc Flash Study (Incident Energy Method) | PPE Table Method |
Applicability | Universal; works for any system. | Limited to simple systems with specific parameters (e.g., max fault current). |
Accuracy | Site-specific and precise. | Generic and conservative; often results in requiring higher, unnecessary PPE levels. |
Compliance | Gold standard for demonstrating OSHA’s “reasonable estimate.” | May not be defensible if system parameters fall outside the table notes. |
A key outcome of a study is identifying high-hazard areas and providing solutions.
Sometimes, simply adjusting a breaker’s settings can dramatically lower incident energy without compromising protection. This is often the most cost-effective mitigation method. Using a maintenance mode setting can temporarily lower trip times while work is being performed.
Method | How It Works | Pros | Cons |
Arc-Flash Detection Relays | Uses light sensors to detect an arc in <1ms and trip the breaker instantly. | Extremely fast; drastically reduces incident energy. | Higher cost; requires installation and wiring. |
Zone Selective Interlocking (ZSI) | Allows breakers to communicate, ensuring the one closest to the fault trips instantly. | Improves coordination and reduces clearing time. | Only works with compatible electronic trip units. |
High-Resistance Grounding (HRG) | Limits the available current during the most common type of fault (phase-to-ground). | Prevents arc flashes from single-phase faults. | Does not protect against phase-to-phase faults. |
Current-Limiting Devices | Fuses or breakers that trip so fast they prevent the fault current from reaching its peak. | Very effective for specific applications. | Can be difficult to coordinate; may need replacement after tripping. |
The safest approach is always to work de-energized. When that’s not feasible, use:
An arc flash study is a living document.
A revision (updating a small part of the model) is needed for minor changes. A full restudy is required for major system modifications or after the 5-year review period mandated by NFPA 70E.
Labels should be updated whenever the study model is revised. Including the study date on the label helps track its validity. For partial updates, only the affected equipment needs to be re-labeled.
NFPA 70E requires that qualified electrical workers receive safety training at least every 3 years. This training should cover hazard identification, reading arc flash labels, selecting PPE, and emergency procedures.
Selecting the right engineering firm is critical.
Look for:
IEEE 1584.1 is a new guide that defines the recommended practice for the specification and delivery of arc flash studies. Your Request for Proposal (RFP) should require the provider to follow this standard.
(A downloadable RFP template would be linked here.)
Problem: A manufacturing plant had a 480V switchboard with a dangerously high incident energy of 45 cal/cm², requiring cumbersome and expensive PPE.
Approach: The arc flash study provider analyzed the coordination between the main and feeder breakers. The TCC snippet showed the main breaker was too slow.
Mitigation: By slightly adjusting the main breaker’s short-time delay setting, the clearing time for a fault on the feeder was reduced from 0.5 seconds to 0.1 seconds.
Result: The incident energy dropped to 7.2 cal/cm². This allowed workers to use standard Category 2 PPE, improving safety and efficiency while avoiding the potential for a catastrophic, downtime-inducing event.
Yes, NFPA 70E requires the arc flash risk assessment to be reviewed at least every five years, or when major changes occur. This review often necessitates updating the study to ensure its accuracy.
Incident Energy (IE) is the precise calculated thermal energy (e.g., 7.2 cal/cm²). A PPE Category (e.g., CAT 2) is a range of IE values that corresponds to a pre-defined set of protective clothing and equipment.
Yes, a phased approach is possible, but it’s most effective to study an entire electrical system or subsystem at once. Studying isolated parts can lead to inaccuracies because electrical systems are interconnected.
The most helpful documents are up-to-date single-line diagrams, panel schedules, previous electrical studies, and a letter from your utility stating the available fault current.
Once the study is complete and labels are printed, a team can typically install hundreds of labels per day. The process usually takes 1-3 days for an average-sized facility.
Ready to ensure your facility is safe and compliant? Contact us for a detailed scope and estimate for your arc flash study.
